Allegro
50 foots heavy duty explosion proof extension cord 20 AMP, 220 VAC. Weatherproof and abrasion resistant
RA9540-60EX
$2,415.00
Return conditions:
No returnable if used. For more information about our return policy, please refer to the Orders and Returns.
50 ft. 20 AMP, 220 VAC. explosion-proof extension cord with NEMA 20A connection. The outer jacket is a flame retardant, water and oil resistant, yet flexible and abrasion resistant. This cord meets CSA specifications. Classified Class I, Division 1&2 groups B, C, D and Class II, Division 1&2 groups F and G. Note that for group F do not use in the presence of conductive dust. Ideal for use with explosion proof fans or blowers such as the.
Allegro Industries manufacturer's code: 9560-50EX
Cord Specifications:
- 50 ft / 15.24 m length
- Wire type: 10/3 AWG
- Approval: Classified Class I, Division 1&2 groups B, C, D and Class II, Division 1&2 groups F and G. Note that for group F do not use in the presence of conductive dusts. (Most coal dust is not electrically conductive).
- Maximum amperage 30 A
- NEMA 20A, explosion proof male connector
- NEMA 220 VAC, 20A female connector with spring-loaded protective cover
- Operating temperature -40°F to 221°F (-40°C to 105°C)
- Weight 15.5 lb / 7.03 kg
- Color black
RA9540-60EX
Data sheet
- Type of product
- Safety equipment
- Main category
- Industrial accessories
- Sub category
- Asbestos decontamination
- Name of the product
- Extra heavy duty explosion proof extension cord 50 ft 20 AMP, 220 VAC
- Series of products
- COM-PAZ-IAL PLASTIC BLOWERS
- Product code
- RA9540-60EX
- Product use
- Fans and accessories for confined spaces
- Approved/Certified
- Classified Class I, Division 1 & 2 groups B, C, D and Class II, Division 1 & 2 groups F and G
- Manufacturer
- Allegro industries
- Country of origin
- United State of America
- Reusable
- Reusable with careful inspection and proper installation
- Recommended use temperature
- Operating temperature -40°F to 221°F / -40°C to 105°C
- Includes
- A spring-loaded door that prevents dust from entering the outlet when not in use
- Property of the material
- The outer sheath is flame retardant, water and oil resistant, yet flexible and abrasion resistant
- Maximum current
- Maximum current 30 A
- Wire type
- Wire type: 10/3 AWG
- Cord length
- Length of 50 ft / 15.24 m
- Type of plug
- NEMA 20 A, 220 VAC explosion-proof type connector, female connector with spring cover
- Material1
- Copper
- Material2
- Rubber
- Material3
- Steel
- Length (in/cm)
- 16 in / 40.6 cm
- Width (in/cm)
- 8 in / 20.3 cm
- Height (in/cm)
- 16 in / 40.64 cm
- Weight (lb/kg)
- 19 lb / 8.6 Kg
- Color
- Black/Grey
- Return conditions
- No returnable if used. For more information about our return policy, please refer to the "Orders and Returns" link on the home page
- Caution
- Approval: Note that for Group F do not use in the presence of conductive dusts. (Most coal dusts are not electrically conductive)
