Safety shirt, navy blue, FR-TECH 7 oz fireproof, size small to 4XL, Pioneer V2541440, model 7742SF, sold by unit
V131-L
$119.65
Pioneer FR-Tech 7 oz fire-retardant work shirt, navy blue, Arc 2 rated (ATPV 10 cal/cm2). Flame-resistant cotton-nylon fabric, non-conductive buttons, retroreflective striping. Sizes S to 4XL.
Return conditions:
No returnable if used. For more information about our return policy, please refer to the Orders and Returns.
FR-Tech Pioneer 7 oz fireproof safety shirt, Arc 2 rated, for work exposed to arc flash
Pioneer manufacturer no.: V2541440, model 7742SF, sold by unit
This navy blue Pioneer FR-Tech fire-retardant work shirt is designed for workers exposed to flame and arc-flash hazards. Arc 2 rated, it delivers a thermal protective performance (TPP) of 9 cal/cm2 and an ATPV value of 10 cal/cm2 (risk category CAT 2). Available in sizes small (S) to 4X-large (4XL), select your size from the drop-down menu above.
The shirt is made of 88 % premium cotton blended with 12 % high-tenacity nylon, a 7 oz (240 g/m2) FR-Tech fabric that combines strength, breathability and comfort for long wear. It is sewn with intrinsically flame-resistant aramid thread and fitted with non-conductive flame-resistant buttons, a build tailored to electrical environments. Flame resistance is guaranteed for the life of the garment.
Key features of the Arc 2 safety shirt
This shirt brings together the features expected of a professional protective garment for hot work and electrical work:
- FR-Tech 7 oz (240 g/m2) fabric: 88 % cotton and 12 % nylon, flame resistant and breathable.
- Arc 2 rated: TPP of 9 cal/cm2 and ATPV value of 10 cal/cm2, risk category CAT 2.
- StarTech retroreflective striping: silver retroreflective bands alternating with fluorescent yellow (2 vertical at front, 2 cross-X at back, 1 horizontal at the waist and 1 around each arm) to improve worker perception in technical areas.
- Non-conductive flame-resistant buttons and seams sewn with intrinsically flame-resistant aramid thread.
- 2 chest pockets with flaps, adjustable cuffs with 2 buttons and a pen pocket.
- Sizes small (S) to 4X-large (4XL), men's cut, sold by unit.
Note on color: navy blue is a discreet color that hides soiling well, but it is not considered a high-visibility color. For a job that requires high visibility, choose a fluorescent orange or yellow model instead.
Job sites and sectors where this product is required
This fire-retardant shirt suits any job where an arc-flash risk assessment calls for an Arc 2 rated garment:
- Work on energized electrical panels and switchgear exposed to arc flash.
- Industrial maintenance of substations and distribution stations.
- Electrotechnical work in factories, commercial buildings or data centers.
- Connection and testing on power equipment (motors, drives, breakers).
- Hot work and industrial maintenance where flame protection is required.
Care and inspection of your fire-retardant shirt
Careful maintenance preserves the garment's flame-resistant properties. Before washing, empty the pockets and fasten the buttons. Wash in warm water (maximum 104 F or 40 C) with like colors, using a mild liquid detergent (pH of 10 or less). Do not use detergent containing bleaching agents or animal fat, nor chlorine or hydrogen-peroxide bleach. Do not use fabric softener or dryer sheets, as they make the garment flammable. Shake the shirt as it comes out of the washer and hang it to dry, or tumble dry on the cotton setting without exceeding 149 F (65 C). Cover the retroreflective tape before any ironing. Inspect the garment before each use for cuts, burns or excessive wear.
FAQ: Frequently asked questions about the FR-Tech Arc 2 shirt
Which standards does this shirt meet?
This shirt complies with CGSB 155.20-2017 and NFPA 2112-2018, is UL listed, and also meets ASTM F1506-2020A, NFPA 70E and CSA Z462-22. It is Arc 2 rated with an ATPV value of 10 cal/cm2 and a thermal protective performance (TPP) of 9 cal/cm2.
Is the navy blue shirt a high-visibility garment?
No. Navy blue is a discreet color that hides soiling and carries retroreflective striping, but it is not considered a high-visibility color. For high visibility, choose a fluorescent orange or yellow model.
How do I choose my size?
The shirt comes in sizes small (S) to 4X-large (4XL) in a men's cut. Select your size from the drop-down menu at the top of the page. If you are between two sizes, choose the larger one to keep freedom of movement.
Complementary suggestions
To complete the outfit, pair this shirt with its matching Pioneer FR-Tech 7 oz cargo pants (V7764) and protect your hands with Arc 2 fire-retardant neoprene-palm gloves (GS13FRNE). If you prefer one-piece protection, see the orange Arc 2 fire-retardant coverall (V1765). Since the electrical work zone must always be delimited, mark it with red DANGER barricade tape (ECT3RE9) and a shock-hazard sign (ECD400). Under Accessories at the bottom of the page.
V131-L
Data sheet
- Product group
- Safety equipment
- Main category
- Personal protection
- Sub category
- Safety clothing
- Sub sub category
- Pants, shirt, coverall
- Name of the product
- Safety shirt
- Series of products
- FR-Tech®-Arc Gard®
- Product code
- V131
- Sort by keywords
- Traffic shirts
- Approved/Certified
- Conforms to CGSB 155.20-2017, NFPA 2112-2018, UL listed. Also complies with CSA Z96-15 class 1 level 2 and class 1 fire-retardant level
- Approved/Certified for black, blue, red and rose
- Complies with CSA standard Z96-22 class 1 level 2
- Approval/Certification for clothing FR
- Complies with CGSB 155.2020 and NFPA 2112-2018 and is UL, ASTM F1506-2020A, NFPA 70E and CSA Z462-22 listed, ARC 2 with an ATPV value of 10 cal/cm² and a thermal protection rating (TPP) of 9 cal/cm²
- Manufacturer
- Pioneer®
- Country of origin
- China
- Thermal protection
- TPP value: 9 cal/cm² ARC ATPV rating 10 cal/cm² CAT 2
- About APTV and TPP values-1
- We have observed differences between the values given in the manufacturer's data sheets for APTV and TPP. These values may vary according to the different standards considered
- About APTV and TPP values-2
- These values are subject to change according to the evolution of tests established according to the reference year of the said standard. The values displayed on our website correspond to those indicated on the garments
- Fineness of the knitting
- FR-Tech® 7 oz - 240 g/m²
- Flame Resistance
- Flame resistant
- Choice of format
- Size small (S) to 4 extra-large (4XL) available
- Gender
- Male
- Features
- With alternating silver retroreflective and fluorescent yellow stripes. 2 vertical stripes on the front, 2 crossed X stripes on the back, 1 horizontal stripe on the waist and 1 stripe around each arm
- Additional Features
- 2 chest pockets with flaps, adjustable wrists with 2 buttons, pen slot on chest pocket
- Characteristic adding safety
- Flame resistance guaranteed for the life of the garment
- Precision on the color of the material and their visibilities
- It is important to note that navy blue shirts are not commonly used for high visibility, as they are not as visible as fluorescent or bright colors. Navy blue shirts are often used for aesthetic reasons or to avoid showing dirt
- Includes
- Non-conductive FR buttons
- Includes 2
- Sewn with aramid inherently FR thread
- Property of the material
- Fire retardant
- Material1
- 88 % cotton
- Material2
- 12% nylon
- Material3
- StarTech® reflective strips
- Washable
- Wash in lukewarm water with similar colors and do not exceed (104⁰F or 40⁰C). Wash Use a mild liquid detergent (PH of 10 and below). Do not use detergents containing bleach or animal fat
- Washable2
- Do not use bleaches containing chlorine (sodium hypochlorite) or hydrogen peroxide in the wash cycle. Do not use fabric softeners, as they render garments flammable
- Drying
- Do not use fabric softeners, starch and/or fabric softener sheets. Garments can be iron-pressed, tumble-dried, tunnel-dried or hung in a cool place
- Drying2
- Cover retroreflective tape before ironing. As far as the drying temperature is concerned, it should not exceed 149⁰F or 65⁰C. Use the "cotton" setting for drying. Do not over-dry. Do not use starch during drying
- Before/after washing tips
- Before washing, be sure to empty all garment pockets and close all zippers, snaps and hook-and-loop fasteners. After washing, shake the garment to remove wrinkles and hang to dry in a cool, well-ventilated place
- Dimensions of the product
- The dimensions of the product depend on the size selected by the customer.
- Length (in/cm)
- 13 in / 33 cm
- Width (in/cm)
- 11 in / 27.94 cm
- Height (in/cm)
- 1 in / 2.54 cm
- Weight (lb/kg)
- 1.3 lb / 0.58 Kg
- Sold by
- Unit
- Color
- Blue/Gray/Yellow
- Return conditions
- No returnable if used. For more information about our return policy, please refer to the "Orders and Returns" link on the home page
