- New
DBI-SALA X200 Vest Style harness class ALP Wind Energy
FPH1402127ALP
$642.00
3M DBI-SALA ExoFit X200 vest-style Class ALP (fall arrest + ladder climbing + positioning) harness for wind energy. 420 lb capacity. Patented double-locking buckles, stand-up dorsal ring, sub-pelvic strap. CSA Z259.10-18 compliant. Small, Medium, Large, X-Large, 2X-Large.
Return conditions:
No returnable if used. For more information about our return policy, please refer to the Orders and Returns.
DBI-SALA X200 Vest Style harness class ALP Wind Energy
The ExoFit X200 Class ALP (fall Arrest, Ladder climbing and Positioning) harness by 3M DBI-SALA is designed for professionals demanding reliability, comfort and safety during work at height, particularly in wind energy applications. Ideal for: tower climbers, linemen and versatile work at height. Made in the USA, compliant with CSA Z259.10-18. This harness is vest style, with vertical shoulder straps for easy donning and optimal comfort. It features a padded work belt at the waist with a tongue buckle, providing stable positioning and lumbar support for extended work at height.
| Size | Sylprotec Code | DBI-SALA Model | 3M Purchase Code |
|---|---|---|---|
| Small | FPH1402125ALP | 1402125 | 7100281823 |
| Medium | FPH1402126ALP | 1402126 | 7012817869 |
| Large | FPH1402127ALP | 1402127 | 7012817870 |
| X-Large | FPH1402128ALP | 1402128 | 7012817871 |
| 2X-Large | FPH1402129ALP | 1402129 | 7012817872 |
Technical description : features and components
This ExoFit X200 safety harness features a dorsal, sternal and hip D-rings with automatic vertical positioning (stand-up) and anti-slip plate. The patented 3M double-locking quick-connect buckles keep the adjustment secure throughout the shift, eliminating frequent readjustments. The torso buckle is swivel and lockable. The sub-pelvic strap prevents orthostatic suspension syndrome in the event of a fall.
The 6,000 lb polyester webbing offers superior UV and chemical resistance. Zinc-plated alloy steel hardware is unpainted for easy visual inspection. Color-coded webbing simplifies donning. Available in: Small, Medium, Large, X-Large, 2X-Large.
Load capacity and certified safety standards
Maximum load: 420 lb / 190 kg including clothing, tools and equipment. Compliant with CSA Z259.10-18 for the Canadian market. Made to order by 3M. Allow approximately 1 month lead time.
Materials : strength, durability and light weight
6,000 lb (27 kN) polyester webbing: superior resistance to acids and UV. Unpainted light aluminum-alloy D-rings and slides, and quick-connect leg buckles of hybrid aluminum-alloy and zinc-plated-steel construction (light weight and strength at the highest-stress points): facilitates visual defect inspection with advanced material engineering specific to 3M DBI-SALA harnesses. Multi-color webbing: quick identification of anchor points and adjustments. Plastic tips on webbing ends: prevent fraying over time.
Application and recommended uses
Suitable for: tower climbers, linemen and versatile work at height. Meets the requirements of Canadian Labour Code and CNESST (Quebec) regulations for work at height. Sizes available: Small, Medium, Large, X-Large, 2X-Large.
Inspection and service life : verification guide
Inspect before each use: check for cuts, fraying, broken stitching and deformed hardware. Inspection by a qualified person is required at least annually. Recommended service life: 5 years with regular use. Any harness subjected to a fall must be removed from service and destroyed immediately. Sylprotec offers annual inspection by a qualified technician.
Care and cleaning to extend service life
Clean with mild soap and lukewarm water (max 37 C / 98.6 F). Never use bleach, solvents or abrasive products. Air dry away from direct sunlight. Store hanging in a clean, dry location away from chemicals and heat sources.
FAQ - Frequently Asked Questions
What is the difference between Class ALP and a standard Class A harness?
A Class A harness only provides fall arrest through the dorsal D-ring. Class ALP combines three functions: fall Arrest (dorsal), Ladder climbing / limited access (sternal D-ring) and work Positioning (hip D-rings). This ExoFit X200 harness therefore covers jobs requiring fall protection, work positioning and vertical climbing at once, without switching equipment.
Can the dorsal, sternal and hip D-rings be used at the same time?
Each D-ring has a specific function and must never be used outside its intended purpose. The dorsal ring is for fall arrest, the sternal ring for guided ascent and the hip rings for positioning with a restraint lanyard. Use the ring matching the current task; hip rings are never used for fall arrest. Always consult the manufacturer's instructions and applicable regulations.
Why is there about a 1 month lead time for this harness?
This model is made to order by 3M and is not kept in regular stock. Allow approximately 1 month from the order date. For an urgent need, contact Sylprotec: we can check availability and suggest an equivalent in-stock harness when possible.
Complementary Suggestions
To complete your fall protection system, add a leading-edge SRL retractable (FPLR73302-40LE) or an energy-absorbing lanyard (FPL1340125C) as your fall arrest connection. Protect the head with a Peak T2 helmet with integrated chin strap (TA222), the eyes with safety glasses (YA11514) and hearing with earplugs (OA1250). For the job, add suitable gloves (G378GKGVBE) and a flame-resistant garment (V1766).
Under “Accessories” at the bottom of the page. For safe storage and transport of your equipment at height, a Peakworks bag (FPBAG) keeps your gear clean and inspection-ready.
FPH1402127ALP
Data sheet
- Product group
- Safety equipment
- Main category
- Personal protection
- Sub category
- Fall protection
- Sub sub category
- Fall protection safety harness
- Name of the product
- Safety harness
- Series of products
- ExoFit X200
- Product code
- FPH1402127APL
- Approved/Certified
- Compliant with CSA Z259.10-18
- Manufacturer
- 3M DBI-SALA
- Country of origin
- United State of America
- Choice of format
- Size small (S) to double extra large (2XL) available
- Reusable
- Reusable with careful inspection and proper installation
- Features
- Patented 3M double-locking quick-connect buckles. Dorsal, sternal and hip D-rings. Versatile.
- Characteristic adding safety
- Polyester webbing with a 6,000 lb (26.7 kN) strength rating.
- Comfort features
- Equipped with a sub-pelvic strap providing greater comfort during suspension.
- Characteristics of metal parts
- Unpainted metal parts for easy visual inspection; patented 3M self-locking quick-connect leg buckles made of aluminum alloy and zinc-plated steel (hybrid construction), combining light weight and strength
- Feature that facilitates use
- The straps have distinct colors for easy donning
- Includes
- With dorsal (stand-up), sternal and hip (pair) zinc-plated steel D-rings
- Includes 2
- Equipped with a padded work belt at the waist with a tongue buckle for stable positioning and lumbar support during extended work at height
- Includes 3
- The ends of the straps have plastic tips to prevent fraying and allow the user to adjust the harness easily even when wearing work gloves
- Property of the material
- Polyester straps offer better resistance to acidic chemicals
- Classification
- Class ALP — dorsal (A, fall arrest) + sternal (L, climbing) + hips (P, work positioning)
- Type of harness
- Vest-style harness
- Material1
- Polyester
- Material2
- Aluminum
- Material3
- Aluminum alloy / zinc-plated steel
- Weight (lb/kg)
- 4.46 lb / 2.02 kg
- Availability
- Please note: Available only on special order
- Sold by
- Unit
- Color
- Gray/Blue
- Return conditions
- No returnable if used. For more information about our return policy, please refer to the "Orders and Returns" link on the home page
- Caution
- The maximum weight supported is 420 lb / 190.5 kg, including clothing, tools, etc.
