Lad-Saf DBI-SALA 3M ladder anchor post 6116026, 19.1 x 7.1 x 240 cm
FPA6116026
$1,091.75
Removable Lad-Saf DBI-SALA 3M 6116026 ladder anchor post for fixed and covered ladders, steel, eye bolt for self-retracting lifeline. Slides into bracket 6116027.
Return conditions:
No returnable if used. For more information about our return policy, please refer to the Orders and Returns.
Removable Lad-Saf DBI-SALA 3M ladder anchor post 6116026, 7.5 x 2.8 x 94.5 in (19.1 x 7.1 x 240 cm)
3M purchase code: 7100250926, model: 6116026
The Lad-Saf DBI-SALA 3M ladder anchor post 6116026 is a removable steel anchor post designed for fixed ladders and especially suited to covered ladders found in man-holes. Its integrated, offset eye bolt allows a three-way self-retracting lifeline to be attached, making it an ideal top anchor point for a winch or an emergency extraction system in confined spaces.
Removable, it is set in place as needed and taken out after use: it slides into the bolted lower bracket 6116027 fixed to the structure. Its capacity is 310 lb (141 kg) in fall arrest and 350 lb (158.7 kg) in work support, for one user. Weighing 22.2 kg (49 lb), it integrates with the Lad-Saf anchorage and flexible cable system range.
Benefits of the Lad-Saf 6116026 anchor post
- Removable anchor post for fixed and covered ladders (man-holes)
- Offset eye bolt for a three-way self-retracting lifeline
- Top anchor point for a winch or confined-space emergency extraction
- Steel construction
- Slides into the bolted lower bracket 6116027
- Capacity 310 lb (141 kg) fall arrest, 350 lb (158.7 kg) work support
Steel anchor post specifications
- Product type: removable ladder anchor post
- Material: steel
- Dimensions: 7.5 x 2.8 x 94.5 in (7.5 x 2.8 x 94.5 in (19.1 x 7.1 x 240 cm))
- Weight: 22.2 kg (49 lb)
- Number of users: one
- Capacity: 310 lb (141 kg) fall arrest; 350 lb (158.7 kg) work support
- Installation type: temporary (removable)
- Fastening: slides into the bolted lower bracket 6116027
- Compliant with OSHA 1926.502
Role of the anchor post in the Lad-Saf system
The 6116026 anchor post serves as a removable top anchor point at the head of a fixed or covered ladder. Its offset eye bolt receives a three-way self-retracting lifeline or a winch, allowing both fall protection during the climb and emergency extraction of a worker in a confined space. Removed after use, it clears the access and quickly reinstalls into the lower bracket bolted to the structure.
Compatibility and mounting of the anchor post
The 6116026 anchor post slides into the bolted lower bracket 6116027 fixed to the structure. It integrates with the Lad-Saf anchorage system range and combines with a DBI-SALA winch or three-way self-retracting lifeline. The exact configuration (lower bracket, winch or SRL, rescue devices) must be validated with a competent person and per the 3M manufacturer instructions.
Worksites and industries for the Lad-Saf anchor post
- Vertical access on fixed and covered ladders (man-holes, confined spaces)
- General industry, utilities, oil and gas
- Maintenance of networks, tanks and elevated structures
- Rescue and emergency extraction in confined spaces
Anchor post inspection and maintenance
Before each use, inspect the post, the eye bolt, its attachment to the lower bracket and the condition of the steel. Check for corrosion, cracks or deformation. Any damaged component must be removed from service. A formal inspection by a competent person other than the user is required at least once a year, per 3M manufacturer instructions and applicable provincial regulations. Any repair must be performed by 3M DBI-SALA or a competent person. See our services to learn more.
FAQ about the Lad-Saf 6116026 anchor post
What is this anchor post for?
It serves as a removable top anchor point at the head of a fixed or covered ladder, to attach a three-way self-retracting lifeline or an extraction winch.
Is it permanent or removable?
It is removable: it is set in place as needed, then taken out after use. Only the 6116027 lower bracket stays bolted to the structure.
What does it attach to?
It slides into the bolted lower bracket 6116027 fixed to the structure.
How many users and what capacity?
It is intended for one user, with a capacity of 310 lb (141 kg) in fall arrest and 350 lb (158.7 kg) in work support.
Which standard does it comply with?
It complies with OSHA 1926.502. Confirm the applicable compliance for your job site with a competent person.
Complementary fall protection equipment suggestions
The maintenance technician descends into a man-hole along a covered ladder, protected by a self-retracting lifeline attached to the anchor post. A wrong move or unsuitable equipment is enough to turn a routine descent into a serious fall. On this type of job site, he wears his full personal protective equipment: a Class L sternal-D-ring safety harness (FPH140102XCAL), cut-resistant gloves (G100), safety glasses (YA11329), a protective helmet (TA222), a high-visibility garment (VV20) and hearing protection, disposable earplugs (O1100).
To build the complete vertical fall arrest system, pair this product with the other Lad-Saf components: the vertical cable safety system (FPA6100219); the cable safety sleeve (FPA5000338); the flexible lifeline counterweight (FPA5901583); the stainless-steel pole cable guide (FPA6100136); the galvanized pole intermediate guide (FPA6100430); the end-of-line cable guide (FPA61005XX); and the system instructions and label plate (FPA6100252). Also plan a RollGliss R550 rescue and descent device (FPLR550) for controlled descent, and mark off the area at the foot of the ladder with a DANGER barricade tape (ECT3RE9).
FPA6116026
Data sheet
- Product group
- Safety equipment
- Main category
- Personal protection
- Sub category
- Fall protection
- Sub sub category
- Rope & rope grab
- Name of the product
- Lad-Saf DBI-SALA 3M end-of-line cable guide for straight ladder
- Product code
- FPA6116026
- Product use
- Vertical access on fixed straight ladders ; utilities, wind energy, oil and gas, power transmission.
- Approved/Certified
- ANSI A14.3-1992, OSHA 1910.27, FAA RR-S-001301
- Manufacturer
- 3M DBI-SALA
- Country of origin
- United State of America
- Reusable
- Reusable with careful inspection and proper installation
- Features
- Cable guide with a non-metallic rubber contact area and galvanized or stainless steel mounting hardware, rugged and corrosion resistant.
- Additional Features
- The worker must use a 5/8" (16 mm) diameter rope approved for fall arrest
- Characteristics of the strap or cable
- Integrates into a Lad-Saf system serving up to 4 workers.
- Characteristics of metal parts
- Non-painted metal parts
- Feature that facilitates use
- Bolts onto a straight-ladder rung, for a quick and customizable installation.
- Includes
- Bypassable cable guide that bolts onto a straight-ladder rung, with a non-metallic rubber contact area, available in galvanized or stainless steel.
- Worker’s weight
- 200 to 386 lb / 90.72 to 175.09 Kg
- Material1
- Galvanized steel or stainless steel
- Material2
- Rubber
- Washable
- Wash in warm water, 98.60°F/ 37°C. Never use bleach or other abrasive or chemical products on your lanyard. Air dry
- Length (in/cm)
- 5.55 in / 14.1 cm
- Width (in/cm)
- 2.65 in / 6.7 cm
- Height (in/cm)
- 7.5 in
- Weight (lb/kg)
- 49.0 lb
- Sold by
- Unit
- Color
- Gray/Black
- Return conditions
- No returnable if used. For more information about our return policy, please refer to the "Orders and Returns" link on the home page
- Caution
- Maximum supported worker weight of 200 lb to 386 lb / 90.72 kg to 175.09 kg, including clothing, tools and equipment
