ExoFit X100 Class ALP Vest Style Tower Climbing Harness DBI-SALA 3M
FPH1401142CALP
$686.60
3M DBI-SALA ExoFit X100 Class ALP fall arrest, climbing and positioning harness designed for tower climbing and wind turbine work. 4 D-rings: dorsal, sternal, and 2 lateral hip rings. Quick-connect pivoting buckles. CSA Z259.10-18 compliant. Available in Small, Medium, Large, X-Large and XXL.
Return conditions:
No returnable if used. For more information about our return policy, please refer to the Orders and Returns.
ExoFit X100 Class ALP Tower Climbing Harness DBI-SALA 3M
The 3M DBI-SALA ExoFit X100 Class ALP harness is specifically designed for tower climbing, telecom structures and wind turbine work. It combines three functions in one: fall arrest (dorsal D-ring), vertical lifeline climbing (sternal D-ring) and work positioning (lateral hip D-rings). This harness is vest style, with vertical shoulder straps for easy donning and optimal comfort. It features a rigid seat strap with seat pad for comfortable, stable seated positioning during extended suspension work (tower and wind-turbine climbing), plus a padded work belt. It also includes an integrated adapter to easily connect an individual self-retracting lifeline. Made in the USA, compliant with CSA Z259.10-18.
| Size | Sylprotec Code | DBI-SALA Model | 3M Purchase Code |
|---|---|---|---|
| Small | FPH1401140CALP | 1401140C | 7012817619 |
| Medium | FPH1401141CALP | 1401141C | 7012817621 |
| Large | FPH1401142CALP | 1401142C | 7012817623 |
| X-Large | FPH1401143CALP | 1401143C | 7100328123 |
| XXL | FPH1401144CALP | 1401144C | 7012817626 |
Technical description : 4 D-rings, quick-connect buckles and components
This harness features 4 zinc-plated steel D-rings: 1 dorsal stand-up D-ring with anti-slip back pad, 1 sternal (front) D-ring for connection to a vertical lifeline during climbing, and 2 lateral hip D-rings for hands-free work positioning. Quick-connect pivoting buckles keep the fit secure throughout the shift. The integrated sub-pelvic strap prevents orthostatic suspension syndrome in the event of a fall.
Color-coded straps simplify donning. Plastic end caps prevent fraying. The integrated 3M CSID (Connected Safety ID) enables inventory management and inspection tracking. Available in 5 sizes: Small, Medium, Large, X-Large and XXL.
Load capacity and CSA Z259.10-18 certification
Maximum load: 310 lb (140.6 kg) including clothing, tools and equipment. Compliant with CSA Z259.10-18 for the Canadian market. Made to order by 3M : allow approximately 1 month for delivery.
Materials : UV resistance, acid resistance and easy inspection
High-strength polyester webbing: superior resistance to acids, UV and weather. Unpainted zinc-plated alloy steel hardware: direct visual inspection without masking corrosion. Leg and back padding for comfort during long climbs. Color-coded straps for quick identification of each attachment point when donning.
Application : tower climbing, wind turbines and telecommunications
Ideal for: telecom tower climbing, electrical pylons and wind turbine structures. Class ALP combines fall arrest (A), vertical lifeline climbing (L) and work positioning (E). Available in 5 sizes (Small to XXL). Use with a vertical cable grab connected to the sternal ring during ascent.
Mandatory inspection before each use
Inspect before every use: check for wear, tears, buckle or D-ring deformation, webbing degradation or chemical contamination. Qualified-person inspection at regular intervals (90 days recommended). Maximum service life: 5 years from first use. Remove from service immediately after any fall or impact, even with no visible damage. Sylprotec offers fall protection equipment inspection services.
Care and cleaning
Wash in warm water (37°C / 98.6°F) with mild soap. Never use bleach, solvents or abrasive products. Rinse thoroughly. Air dry away from direct heat and sunlight. Store in a dry location away from UV. Replace if heavily contaminated or exposed to aggressive chemicals.
Frequently asked questions : ExoFit X100 Class ALP Harness
What is the difference between Class AL and Class ALP?
A Class AL harness combines fall arrest (A) and vertical lifeline climbing (L). Class ALP adds work positioning (E) via lateral hip D-rings, enabling hands-free positioning once at height. This model is therefore more versatile for technicians who need to both climb and work on the structure.
Can this harness be used for general construction?
Yes, but this harness is optimized for tower climbing and wind energy work. For general construction without vertical lifeline climbing, a Class A or AP harness at lower cost is more appropriate. Contact us to select the right harness for your specific work.
What is the integrated 3M CSID?
The CSID (Connected Safety ID) is a chip built directly into the harness. It enables inventory management, inspection date tracking and usage history via the 3M app : without any additional external tag.
Complementary suggestions
To complete your fall protection system, add a leading-edge SRL retractable (FPLR75105-6LE) or an energy-absorbing lanyard (FPL1340180C) as your fall arrest connection. Protect the head with a Peak T2 helmet with integrated chin strap (TA222), the eyes with safety glasses (YASF401BG) and hearing with earplugs (OA101). For the job, add suitable gloves (GMXVSB) and a flame-resistant garment (V7705).
Under “Accessories” at the bottom of the page. For safe storage and transport of your equipment at height, a Peakworks bag (FPBAG) keeps your gear clean and inspection-ready.
FPH1401142CALP
Data sheet
- Product group
- Safety equipment
- Main category
- Personal protection
- Sub category
- Fall protection
- Sub sub category
- Fall protection safety harness
- Name of the product
- Safety harness
- Series of products
- ExoFit X100
- Product code
- FPH140114APL
- Approved/Certified
- Compliant with CSA Z259.10-18
- Manufacturer
- 3M DBI-SALA
- Country of origin
- United State of America
- Choice of format
- Size small (S) to double extra large (2XL) available
- Reusable
- Reusable with careful inspection and proper installation
- Features
- The chest and thigh straps are joined by quick buckles
- Additional Features
- Maximum capacity 310 lb / 140.6 kg including clothing and tools. Self-closing keepers. Integrated SRL adapter. 3M CSID integrated
- Characteristic adding safety
- Polyester webbing with a 6,000 lb (26.7 kN) strength rating.
- Comfort features
- Equipped with a sub-pelvic strap providing greater comfort during suspension.
- Characteristics of metal parts
- Unpainted metal parts for easy visual inspection; quick-connect leg buckles made of zinc-plated steel
- Feature that facilitates use
- The straps have distinct colors for easy donning
- Includes
- With 1 dorsal D-ring in zinc-plated steel
- Includes 2
- Equipped with a rigid seat strap with seat pad and a work belt at the waist, allowing comfortable, stable seated positioning during extended suspension work at height
- Includes 3
- Includes 4 D-rings: 1 dorsal, 1 front / sternal and 2 lateral hip rings for fall arrest, ladder climbing and positioning.
- Property of the material
- Polyester straps offer better resistance to acidic chemicals
- Classification
- Class ALP — dorsal (A, fall arrest) + sternal (L, climbing) + hips (P, work positioning)
- Type of harness
- Vest-style harness
- Material1
- Polyester
- Material2
- Aluminum
- Material3
- Aluminum alloy / zinc-plated steel
- Washable
- Wash with mild soap and lukewarm water at 98.6°F / 37°C. Never use bleach or abrasive chemicals. Air dry only.
- Length (in/cm)
- 11 in / 28 cm
- Width (in/cm)
- 11 in / 28 cm
- Height (in/cm)
- 11 in / 28 cm
- Weight (lb/kg)
- 4.5 lb / 2.04 kg
- Availability
- Please note: Available only on special order
- Sold by
- Unit
- Color
- Gray/Blue
- Return conditions
- No returnable if used. For more information about our return policy, please refer to the "Orders and Returns" link on the home page
- Caution
- The maximum weight of the worker wearing this harness is 310 lb / 140.6 kg, including clothing, tools, etc.
