Degil temporary concrete anchorage connector for fall protection, 400 lb

Temporary concrete anchorage connector for fall protection

The Degil temporary concrete anchorage connector is a removable anchorage point designed for the fall protection of workers at height, on a concrete surface. It installs into a drilled hole and is removed at the end of the job, making it the ideal solution for occasional work sites where a permanent anchor is not required. It serves as an attachment point to connect a harness to a fall protection system.

This anchor is designed by the manufacturer to withstand static forces of 5000 lb (22 kN), in compliance with the ANSI Z359.7 and CE-EN 795 standards. It supports a maximum weight of 400 lb (181 kg). The body is steel, the end termination is 304 stainless steel (better corrosion resistance than other stainless grades) and the spring is zinc-plated steel. Degil manufacturer code: 8523810. Sold individually.

Advantages of the temporary concrete anchor

Rugged and reusable, this anchor provides a reliable, multidirectional fall protection attachment point for occasional work on concrete, with no permanent installation.

Features and safety of the concrete anchor

• Removable temporary anchor for concrete surfaces
• Withstands static forces of 5000 lb (22 kN)
• Compliant with ANSI Z359.7 and CE-EN 795
• Worker capacity: 400 lb (181 kg)
• Usable in all directions up to a 90° angle (floor, ceiling, walls)
• Cable diameter: ¼ in (7 mm); required hole: ¾ in (19 mm)
• 304 stainless steel end termination, zinc-plated steel spring
• Temperature range: -40 °F to 130 °F (-40 °C to 54 °C)

Job sites and industries where this anchor is required

• Occasional work at height on concrete structures
• Construction, renovation and industrial maintenance
• Floor, ceiling or wall interventions
• Any temporary work requiring an anchor point on concrete

About the anchorage point and its installation

Safe installation of this anchor requires concrete at least 5 in (12.7 cm) thick and a minimum compressive strength of 3000 psi (20.7 MPa). The anchor is intended exclusively for concrete surfaces; it is not recommended for wood or steel. Set the device at least 6 in (152.4 mm) from any edge and to a minimum depth of 3 in (76.2 mm). Do not use with a horizontal lifeline system. The manufacturer recommends removing the device at the end of each workday. Consult the installation manual (English only) for the drill bits to use. As with any fall protection anchorage point, assess the fall distance, the free clearance below the worker, the rescue measures and the anchor strength (5000 lb).

Concrete anchor inspection

The worker is responsible for a routine inspection before each use: look for any sign of degradation, wear, malfunction or breakage. Replace the anchor at the first sign of failure. These anchors should also be inspected periodically by a qualified person other than the worker; the more demanding the conditions, the more frequent the inspection. The anchors carry certification labels. Sylprotec offers a fall protection equipment inspection service; see the Services tab.

FAQ about the temporary concrete anchor

Here are the most frequent questions about the capacity, installation and removal of this temporary concrete anchorage connector.

What load does this anchor support?

It withstands static forces of 5000 lb (22 kN) and suits a worker with a maximum weight of 400 lb (181 kg).

On what surface can it be installed?

Exclusively on concrete at least 5 in (12.7 cm) thick and 3000 psi (20.7 MPa). It is not recommended for wood or steel.

Can it be used in all directions?

Yes, up to a 90° angle (floor, ceiling or walls), but never with a horizontal lifeline.

Suggested anchorage and fall protection products

To build a complete fall protection system, this temporary connector combines with the rest of the protection chain. Depending on the support and the type of work, you will choose a temporary, reusable or permanent anchor, then the associated equipment.

Also consider a class A harness (FPH1000A), a panic-lock grab (FPACC), a vertical lifeline rope (FPAC), the complete roofer kit (FPK50), a stainless permanent anchorage connector (FPA826), a reusable roof anchor (FPA827), a door frame anchor (FPA831) and a storage bag (FPBAG). Under "Accessories" at the bottom of the page.
