5K Swivel® zinc plated permanent anchor with steel mounting hardware for fall protection. The innovative swivel design provides 360° D-ring rotation to prevent accidental roll-out when in use. It also provides 180 ° flip to prevent accidental gate load. This anchor can support a weight of 310 lb (141 kg), including clothing, tools and equipment. Sold individually.
Product available while supplies last.
1 item in stock, take the last one, but no more. Customers who order more than we have in stock will be reimbursed for any shortfall.
Peakworks product code: V8221115 or model CP-10010-2.
According to the manufacturer, 5K Swivel® zinc-plated anchor has been designed to withstand a 5000 lb (22 kN). This anchor meets all applicable OSHA and ANSI requirements: CSA Z259.15 and ANSI Z359.18 standards and OSHA requirements.
Anchor weight: 1.1 Lb (0.5 Kg)
About the anchor point:
A safe installation of this anchor requires a smooth surface made of steel to allow a firm footing. The anchor shall be secured on a steel framework which can withstand static forces of at least 5000 lb 22 (KN). The whole structure shall also be verified and approved by a qualified engineer to ensure it is functional and secure. The anchor includes a 5K® steel bolt with hexagonal head and a steel sleeve anchor. For more information, please consult the specifications sheet and the instructions manual, available as PDF documents under the Download tab (English only).
The user of this anchor must be aware of fall hazards surrounding him. Among other factors, is there an adequate fall clearance below the work area? Are there any obstacles in the way? Are there emergency measures in place to recover a fallen worker? These are all questions one must ask himself.
The worker is responsible for visually inspecting his fall protection equipment before each use. During this routine inspection, the worker must note any signs of degradation, malfunction, or breakage. Any anchor showing signs of wear and tear must be scrapped.
On top of this routine inspection, the anchor must be inspected by a qualified person different than the worker. These inspections should be performed more often if your equipment is used in extreme environmental working conditions.
Replace the anchor as soon as it has withstood an impact or arrested a fall. It is recommended to disassemble the anchor and to dispose of each part separately, so as to avoid accidental reuse of the anchor.
Other equipment frequently used with this safety harness:
|Type of product||Safety equipment|
|Main category||Personal protection|
|Sub category||Fall protection|
|Sub sub category||Anchorage & connectors|
|Name of the product||Permanent swivel anchor|
|Approved/Certified||Complies with CSA Z259.15-17 and ANSI Z359.1-2007 standards|
|Country of origin||China|
|Reusable||Reusable with careful inspection and proper installation|
|Features||The innovative swivel design of this zinc-plated steel anchor allows for a 360° rotation of the D-ring to prevent the lanyard from rolling up|
|Additional Features||It also allows for a 180° tilt to eliminate overloading the lanyard's carabiner opening|
|Characteristic adding safety||Designed to withstand static forces of 5000 lbs (22 KN)|
|Worker’s weight||310 lb / 140 Kg maximum|
|Washable||Hand wash with warm water and soap|
|Length (in/cm)||3 in / 7.6 cm|
|Width (in/cm)||3 in / 7.6 cm|
|Height (in/cm)||2 in / 5.08 cm|
|Weight (lb/kg)||1.1 lb / 0.49 Kg|
|Return conditions||No returnable if used. For more information about our return policy, please refer to the "Orders and Returns" link on the home page|
|Caution||The maximum weight supported is 310 lb / 141 kg, which includes the weight of tools and any other equipment carried by the worker|
